AJ65SBTB1-16D

DC input module

Input: 16 points, 24 V DC, positive/negative common, 1-wire, response time: 1.5 ms
External interface: screw terminal block

Technical specification
No. of inputs:	16
Isolation method:	Photocoupler
Rated input voltage:	24V d.c.
Rated input current:	Approx. 7mA
Operating voltage range:	19.2 to 26.4V d.c. (ripple ratio: within 5%)
ON voltage/ON current:	14V or higher/3.5mA or higher
OFF voltage/OFF current:	6V or lower/1.7mA or lower
Input resistance:	Approx. 3.3kΩ
Response time:
OFF—ON:	1.5ms or lower (when 24V d.c.)
ON—OFF:	1.5ms or lower (when 24V d.c.)
Wiring method for common:	16 points/common (2 points)
	(terminal block 1-wire type)
Input format:	Positive/negative common shared type
	(sink/source shared type)
No. of occupied stations:	1 station 32 points assignment (use 16 points)
I/O module power supply:
Voltage:	20.4 to 26.4V d.c. (ripple ratio: within 5%)
Current:	35mA or lower (when 24V d.c., all points ON)
Network speed:	Up to 10Mbps
Network distance:	Up to 1.2km

Features:

Up to 64 I/O modules with a maximum of 32 inputs or 32 outputs each
can be connected
Compact design which is tough and highly shock-resistant
Status indicator LEDs for the inputs
Modules can be positioned in a horizontal arrangement or one of four orientations
on a flat surface.
DIN rail or screw mounting
