AJ65SBTB1-16T

Transistor output module

Output: 16 points, 12 to 24 V DC 0.5 A, sink, 1-wire
External interface: screw terminal block

This remote module is intended to be installed near the control target.

The main advantages are reduced cabling and the capability of acquiring data and operation results of individual machine modules autonomously.

Technical details.

• Manufacturer : Mitsubishi Electric
• AJ65SBTB1-16T
• CC-Link small type remote I / O unit (transistor output, terminal block)
• AJ65SBTB1 – 16T
• Output format : Transistor output (sink type)
• Number of output points : 16 points
• Rated load voltage : DC12 / 24V
• Used load voltage range : DC 10.2 to 26.4 V (ripple ratio within 5%)
• Maximum load current : 0.5 A / 1 point, 3.6 A / 1 common
• Maximum inrush current : 1.0 A less than 10 ms
• Leakage current at OFF : 0.25 mA or less
• Maximum voltage drop during ON : DC 0.3 V or less (TYP.) 0.5 A, DC 0.6 V or less (MAX.) 0.5 A
• Output response time OFF → ON : 0.5ms or less
• ON → OFF : 1.5 ms or less (resistance load)
• Surge suppressor : Zener diode
• Protection function : Overload protection function, overvoltage protection function, overheat protection function
• Output section External power supply Voltage : DC 10.2 to 26.4 V (ripple ratio within 5%)
• Current : 30 mA or less (TYP. DC 24 V, per common) External load current is not included
• Output common method : 16 points 1 common (terminal trapezoid 1 wire type)
• Output isolation method : Photocoupler isolation
• Withstand voltage : Between DC external terminal and ground: AC 500 V for 1 minute
• Insulation resistance : DC external terminal collective to ground: 500 VDC DC insulation resistance meter 10 MΩ or more
• Protection grade : IP2X
• Station type : Remote I / O station
• Number of occupied stations : 1 station
• Unit power supply Voltage : DC 20.4 to 26.4 V (ripple ratio within 5%)
• Current : 50 mA or less (24 VDC, all points ON)
• External wiring connection method : Communication unit, Unit power supply unit: 7 points 2-piece terminal block (M3 screw) I / O power supply unit, input / output unit: 18 points Direct mounting terminal block (M3 screw)
• External dimensions Height (H) : 50 mm
• Width (W) : 118 mm
• Depth (D) : 40 mm
• mass : 0.18 Kg
• Operating ambient temperature : 0 to 55 ° C
• Storage ambient temperature : -20 to 75 ° C
• Ambient operating humidity : 10 to 90% RH, non condensing
• Storage ambient humidity : 10 to 90% RH, non condensing
• Anti-vibration Meets JIS B 3502, IEC 61131-2 When there is intermittent vibration : Frequency: 5 to 8.4 Hz, One amplitude: 3.5 mm Frequency: 8.4 to 150 Hz, Constant acceleration: 9.8 m / s 2 Sweep count: 10 times in X, Y, Z directions
• When there is continuous vibration : Frequency: 5 to 8.4 Hz, One amplitude: 1.75 mm Frequency: 8.4 to 150 Hz, Constant acceleration: 4.9 m / s 2
• Impact resistance : Meets JIS B 3502, IEC 61131-2 (147 m / s 2 , 3 times in each of X, Y and Z directions)
• Use atmosphere : No corrosive gas
• Use elevation : 0 to 2000 m
• Installation location : In the control panel
• Over voltage category : II or less
• Pollution degree : 2 or less
• Shipping Weight : 1.2 Kg
