Mô-đun Beckhoff KL9400
Giá gốc: 3.200.000₫
Giá khuyến mại 3.000.000₫
Technical data | KL9400 |
---|---|
Input voltage | 24 V DC (-15 %/+20 %) |
Output voltage | 5 V DC |
Output current | 2 A for K-bus supply |
Power contacts | max. 24 V DC/max. 10 A |
Short-circuit proof | yes |
Weight | approx. 65 g |
Operating/storage temperature | -25…+60 °C/-40…+85 °C |
Relative humidity | 95 %, no condensation |
Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
Protect. rating/installation pos. | IP20/variable |
Pluggable wiring | for all KSxxxx Bus Terminals |
Approvals/markings | CE, UL, ATEX, IECEx, DNV GL |
Ex marking | ATEX: II 3 G Ex nA IIC T4 Gc IECEx: Ex ec IIC T4 Gc |
