Mô-đun Beckhoff KL9210
Giá gốc: 1.200.000₫
Giá khuyến mại 1.140.000₫
Technical data | KL9210 |
---|---|
Nominal voltage | 24 V DC |
Current load | ≤ 10 A |
Integrated fine-wire fuse | …6.3 A |
Diagnostics | yes |
Power LED | green |
Defect LED | red |
Reported to K-bus | yes |
PE contact | yes |
Shield connection | – |
Renewed infeed | – |
Connection facility to additional power contact | 1 |
K-bus, looped through | yes |
Bit width in the process image | 2 |
Electrical connection to DIN rail | – |
Current consumption K-bus | typ. 10 mA |
Electrical isolation | yes |
Housing width | 12 mm |
Special features | integrated fuse |
Weight | approx. 55 g |
Side by side mounting on Bus Terminals with power contact | yes |
Side by side mounting on Bus Terminals without power contact | yes |
Operating/storage temperature | -25…+60 °C/-40…+85 °C |
Approvals/markings | CE, UL, ATEX, IECEx, DNV GL |
Ex marking | ATEX: II 3 G Ex nA IIC T4 Gc IECEx: Ex ec IIC T4 Gc |
