Màn Hình HMI WEINTEK TK8071IP 7 inch
Giá gốc: 3.300.000₫
Giá khuyến mại 3.180.000₫
| Monitor | 7″ TFT |
| Resolution(WxH dots) | 800×480 |
| Display Brightness(cd / m2) | 350 |
| Contrast | 500:1 |
| Backlight type | LED |
| Backlight Life | > 30,000Hour |
| Display colors | 16M |
| Type | 4 Wire analog resistive |
| Touch Accuracy | Active Area Length (X) ± 2%, Width (Y) ± 2% |
| Flash Storage(MB) | 128 |
| DRAM (MB) | 128 |
| Processor | 32Bit RISC CPU 528MHz |
| Mini USB Download port | USB 2.0 x 1 |
| COM Port | COM1 RS-232, COM2 RS-485 2W/4W |
| Calendar | Built-in |
| Input Power | 10.5~28VDC |
| Power Consumption | 350mA @ 24V |
| Power Isolated Protection | yes |
| Pressure | 500VAC (1Minute) |
| Insulation resistance | Exceed 50 MW at 500VDC |
| Earthquake | 10 to 25Hz (X, Y, Z Direction 2G 30Minute) |
| Shell material | Industrial Plastics |
| DimensionsWxHxD | 200.4 x 146.5 x 34mm |
| Hole size(mm) | 192 x 138 mm |
| Weight(kg) | Approximately 0.52kg |
| Protection class | IP65 Front Panel Protection |
| Storage temperature | -20 ° ~ 60 ° C (-4 ° ~ 140 ° F) |
| Ambient temperature | 0 ° ~ 50 ° C (32 ° ~ 122 ° F) |
| Using ambient humidity | 10% ~ 90% RH (Without condensation) |
| EU CE Authenticate | EN55022: 2010, EN55024: 2010, EN61000-3-2: 2006 + A2: 2009, EN6100-3-3: 2008, AS / NZS CISPR22: 2009 + A1: 2010 |
| Using Software | Simplified Chinese edition EBPro V5.07.01 Or later |
