FD-33G Threaded Type Fiber M3
Giá gốc: 400.000₫
Giá khuyến mại 350.000₫
| Item | Specifications |
|---|---|
| Product Number | FD-33G |
| Part Number | FD-33G |
| Sensing mode | Reflective type |
| Fiber type | Threaded type |
| Fiber head dia. | M3 |
| Fiber head length | 17 mm |
| With sleeve | No |
| Beam direction | Top-view |
| Beam axis dia./ Spot diameter | dia. 0.4mm dia. 0.016 in (FX-MR6), dia. 0.5 mm dia. 0.020 in (FX-MR3), dia. 0.4 mm dia. 0.016 in (FX-MR7), dia. 0.8 to dia. 3.5 mm dia. 0.031 to dia. 0.138 in (FX-MR8), dia. 4.0 mm dia. 0.157 in (FX-MR9) |
| Fiber cable length | 2 m |
| Allowable bending radius | R2 mm |
| Free-cut | Available |
| Semi-custom | Fiber length change |
| Mounting lens | Available |
| Applicable lens | FX-MR6, FX-MR3, FX-MR7, FX-MR8, FX-MR9 |
| Mounting protective tube | Not available |
| Application | General-purpose |
| Environmental resistance : Protection | IP40 |
| Environmental resistance : Ambient temperature MAX | 80 degrees |
| Environmental resistance : Ambient temperature MIN | -55 degrees |
| Sensing range（STD） | 200 mm 7.874 in (FX-500 series) |
| Sensing range（HYPR） | 650 mm 25.591 in (FX-500 series) |
| Sensing range（U-LG） | 380 mm 14.961 in (FX-500 series) |
| Sensing range（LONG） | 270 mm 10.630 in (FX-500 series) |
| Sensing range（FAST） | 95 mm 3.740 in (FX-500 series) |
| Sensing range（H-SP） | 27 mm 1.063 in (FX-500 series) |
