Cảm Biến Quang CX-444-P Panasonic Chính Hãng

Giá gốc: 550.000₫

Giá khuyến mại 500.000₫

Item Specifications
Product Number CX-444-P
Part Number CX-444-P
CE marking directive compliance EMC Directive, RoHS Directive
Adjustable range 20 to 100 mm 0.787 to 3.937 in
(Note) The adjustable range stands for the maximum sensing range which can be set with the distance adjuster. The sensor can detect an object 2 mm 0.079 in [CX-444(-P): 15 mm 0.591 in, CX-442(-P): 20 mm 0.787 in], or more, away.
Sensing range(with white non-glossy paper) 15 to 100 mm 0.591 to 3.937 in
Hysteresis 2 % or less of operation distance(with white non-glossy paper)
Repeatability Along sensing axis: 1 mm 0.039 in or less, Perpendicular to sensing axis: 0.2 mm 0.008 in or less (with white non-glossy paper)
Supply voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less
Current consumption 20 mA or less
Output PNP open-collector transistor
- Maximum source current: 100 mA
- Applied voltage: 30 V DC or less (between output and +V)
- Residual voltage: 2 V or less (at 100 mA source current), 1 V or less (at 16 mA source current)
Output:Output operation Switchable either Detection-ON or Detection-OFF
Output:Short-circuit protection Incorporated
Response time 1 ms or less
Operation indicator Orange LED (lights up when the output is ON)
Stability indicator Green LED(lights up under stable operating condition)
Distance adjuster 5-turn mechanical adjuster
Sensing mode BGS / FGS functions switchable with wiring of sensing mode selection input
Automatic Interference prevention function Incorporated
(Note) Note that detection may be unstable depending on the mounting conditions or the sensing object. In the state that this product is mounted, be sure to check the operation with the actual sensing object.
Protection IP67 (IEC)
Ambient temperature - 25 to +55℃ -13 to +131℃ ℉ (No dew condensation or icing allowed ), Storage: -30 to +70℃ -22 to +158℃ ℉
Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH
Ambient illuminance Incandescent light: 3,000 lx or less at the light-receiving face
Voltage withstandability 1,000 V AC for one min. between all supply terminals connected together and enclosure
Insulation resistance 20 MOhm , or more, with 250 V DC megger between all supply terminals connected together and enclosure
Vibration resistance 10 to 500 Hz frequency, 3 mm 0.118 in amplitude in X, Y and Z directions for two hours each
Shock resistance 500 m/s2acceleration (50 G approx.) in X, Y and Z directions three times each
Emitting element (modulated) Red LED
Emitting element (modulated):Peak emission wavelength 650 nm 0.026 mil
Spot diameter Ø9 mm Ø0.354 in approx.(at 100 mm 3.937 in distance)
Material Enclosure: PBT (Polybutylene terephthalate)
Front cover: Polycarbonate
Indicator cover: Polycarbonate
Cable 0.2 mm24-core cabtyre cable, 2 m 6.562 ft long
Cable extension Extension up to total 100 m 328.084 ft is possible with 0.3 mm2, or more, cable.
Weight Net weight: 55 g approx.
Gross weight: 65 g approx.
