Encoder E6C3-CWZ5GH 1024P/R OMRON Chính Hãng

Giá gốc: 1.300.000₫

Giá khuyến mại 1.200.000₫

Categorise Incremental Shaft model
Diameter 50 mm dia.
Power supply voltage 5 to 12 VDC (-5% to +10%) Ripple (p-p) 5% max.
Current consumption 100 mA max.
Resolution 1024 P/R
Inrush current Approx. 9 A (0.3 ms)
Output phases A, B and Z
Control output Output type NPN voltage output
Output resistance 2 kΩ
Load current 20 mA max.
Residual voltage 0.4 V max. (at sink current 20 mA)
Starting positional point Equipped
Max. response frequency 100 kHz
Phase difference on output 90±45 ° between A and B (1/4 T ± 1/8 T)
Rise and fall times of output 1 µs max. (Cable length: 2m, Sink current 10 mA)
Starting torque 10 mN.m max.
Moment of inertia 3 x 10**-7 kg.m**2 max.
Shaft loading Radial: 50 N
Thrust: 30 N
Max. permissible rotation 6000 r/min
Protective circuit Output short-cut protection
Power supply reverse polarity protection
Ambient temperature Operating: -10 to 70 ℃ (with no icing)
Storage: -25 to 85 ℃ (with no icing)
Ambient humidity Operating: 35 to 85% RH (with no condensation)
Storage: 35 to 85% RH (with no condensation)
Insulation resistance Between charged parts and the case: 100 MΩ min. (at 500 VDC)
Dielectric strength Between charged parts and the case: 500 VAC 50/60 Hz 1 min
Vibration resistance Destruction: 10 to 500 Hz, 2-mm or 150 m/s**2 double amplitude for 11 min 3 times each in X, Y, and Z directions
Shock resistance Destruction: 1000 m/s**2 for 3 times each in X, Y, and Z directions
Degree of protection IEC: IP64
Company standard: Oil resistance
Connection method Pre-wired models (Cable length: 2 m)
Material Case: Zinc alloy
Main Unit: Aluminum
Shaft: SUS420J2
Weight Package: Approx. 400 g
Accessories Instruction manual
