Encoder E6C3-CWZ3XH 200P/R OMRON Chính Hãng

Giá gốc: 1.300.000₫

Giá khuyến mại 1.200.000₫


Categorise Incremental Shaft model
Diameter 50 mm dia.
Power supply voltage 5 to 12 VDC (-5% to +10%) Ripple (p-p) 5% max.
Current consumption 100 mA max.
Resolution 200P/R
Inrush current Approx. 9 A (0.1 ms)
Output phases A, -A, B, -B, Z and -Z
Control output Output type Line driver output
Output voltage Vo: 2.5 V min.
Vs: 0.5 V max.
Load current High level (Io): -10 mA
Low level (Is): 10 mA
Max. response frequency 125 kHz (65 kHz when using phase Z reset)
Phase difference on output 90±45 ° between A and B (1/4 T ± 1/8 T)
Rise and fall times of output 1 µs max. (Cable length: 2 m, Io = -10 mA, Is = 10 mA)
Starting torque Room temperature: 10 mN.m max.
Low temperature: 30 mN.m max.
Moment of inertia 2.0 x 10**-6 kg.m**2 max.
Shaft loading Radial: 80 N
Thrust: 50 N
Max. permissible rotation 5000 r/min
Protective circuit Output short-cut protection
Ambient temperature Operating: -10 to 70 ℃ (with no icing)
Storage: -25 to 85 ℃ (with no icing)
Ambient humidity Operating: 35 to 85% RH (with no condensation)
Storage: 35 to 85% RH (with no condensation)
Insulation resistance Between charged parts and the case: 20 MΩ or higher (500 VDC megger)
Dielectric strength Between charged parts and the case: 500 VAC 50/60 Hz 1 min
Vibration resistance Destruction: 10 to 500 Hz, 2-mm or 150 m/s**2 double amplitude for 11 min 3 times each in X, Y, and Z directions
Shock resistance Destruction: 1000 m/s**2 for 3 times each in X, Y, and Z directions
Degree of protection IEC: IP65
Company standard: Oil resistance
Connection method Pre-wired models (Cable length: 2 m)
Material Case: Aluminum
Main Unit: Aluminum
Shaft: SUS303
Accessories Instruction manual
