Động cơ chính hãng Oriental motor AZM46AK
Giá gốc: 4.800.000₫
Giá khuyến mại 4.680.000₫
| Lead Time1 | Contact your local sales office for product lead-times, available to ship dates and shipping methods. |
Return Policy |
This product cannot be cancelled or returned once the order has been processed. |
Frame Size |
1.1 in |
Motor Length |
1.26 in. |
Basic Step Angle |
0.72º |
Speed-Torque Characteristics |
Speed-Torque Characteristics |
Holding Torque |
6.8 oz-in |
Current per Phase |
0.35 A/phase |
Type |
High-Torque |
Shaft/Gear Type |
Round Shaft (No Gearhead) |
Gear Type |
No Gearhead |
Motor Connection Type |
Connector |
Shaft |
Single |
Step Angle |
0.72 ° |
Connection Type |
New Pentagon (Bipolar) |
Lead Wires |
5 |
Rotor Inertia |
0.049 oz-in² |
RoHS Compliant |
Yes |
Safety Standards |
ULCSACE |
Insulation Resistance |
100 MΩ minimum under normal temperature and humidity, when measured by a 500 VDC megger between the windings and the motor casing. |
Dielectric Strength |
Sufficient to withstand 0.5 kV, 50 Hz or 60 Hz applied for one minute between the windings and casing, under normal temperature and humidity. |
Temperature Rise |
Temperature rise of the coil measured by the Change Resistance Method is 144ºF (80ºC) or less (at rated current, at standstill, five phases energized). |
Insulation Class |
Class B [266ºF (130ºC)], Recognized as Class A 221ºF (105ºC) by UL standard |
Ambient Temperature Range |
14ºF ~ 122ºF (-10ºC ~ 50ºC) (nonfreezing) |
Ambient Humidity |
85% or less (noncondensing) |
Shaft Runout |
0.002 in. (0.05 mm) T.I.R. at top of output shaft |
Concentricity |
0.003 in. (0.075 mm) T.I.R. |
Perpendicularity |
0.003 in. (0.075 mm) T.I.R. |
Radial Play |
0.001 in. (0.025 mm) max. of 1.12 lb. (5 N) |
Axial Play |
0.003 in. (0.075 mm) max. of 2.2 lb. (10 N) |
Radial Load |
0 in. from Shaft End = 5.6 lb0.2 in. from Shaft End = 7.6 lb0.39 in. from Shaft End = 11.7 lb |
Axial Load |
