Công Tắc Hành Trình Hanyoung HY-M908

Giá gốc: 350.000₫

Giá khuyến mại 330.000₫

 Suffix code

Model Code Content
HY - - Digital temperature controller
Apperance 48             48(W) X 48(H) ㎜
72             72(W) X 72(H) ㎜
8000             96(W) X 96(H) ㎜
8200             96(W) X 96(H) ㎜
Input K           K thermocouple
P           RTD Pt 100 Ω (IEC)
Control output M         Relay contact output
Alarm output N       None
O       High alarm (Only for HY-8200)
Control direciton R     Reverse action (Heating control)
Power supply voltage  A   100 - 240 V a.c. 50 - 60 Hz
Range code   Refer to the range and input code

※ Alarm output is available only for HY-8200 model
※ Default set by Proportional control.

· Specification

Input Thermocouple input TC-K
Reference junction
compensation accuracy
±1.5 ℃ (within -10 ~ 50 ℃)
RTD input Pt100 Ω
Allowable wiring resistance 10 Ω or less, but the resistance between 3 wires should be the same)
Input sampling cycle  500 ms
Control
output
Output type Relay : 1C, 250 V a.c. 5A
Control type ON/OFF control, Proportional control (Selective by Internal DIP switch)
Proportional band 1 ~ 10 ℃
Manual reset (MR) 0 ~ 100 %
Control cycle 20 sec
Hysteresis 2 ℃
Output acting Reverse acting(heating)
Alarm
output
Alarm type Model HY-8200 only. High limit alarm
Output type Relay : 1C, 250 V a.c. 5A
Power
supply
Power supply voltage 100 - 240 V a.c. 50 - 60Hz
Voltage fluctuation rate ± 10% of power supply voltage
Insulation Resistance Min. 20 MΩ, 500 V d.c.
Dielectric strength 3,000 V a.c., 50/60 Hz for 1 minute (between 1st and 2nd terminal)
Power consumption ·HY-48 : 2.1 VA      ·HY-72 : 2.5 VA      ·HY-8000 : 2.6 VA     ·HY-8200 : 3.6 VA
Display accuracy ±1% of FS ±1 Digit
Ambient temperature/humidity 0 ~ 50 ℃, 35 ~ 85 % RH (without condensation)
Storage temperature -25 ~ 65 ℃
weight ·HY-48 : 156 g      ·HY-72 : 164 g      ·HY-8000 : 222 g      ·HY-8200 : 232 g




[Range and input code]
Classification Code Input Range (℃)
HY-48 HY-72 HY-8000 HY-8200
Thermocouple 04 TC-K 0 ~ 399
12 - 0 ~ 1199
RTD 02 Pt100 Ω 0 ~ 199
04 0 ~ 399
