Bộ điều khiển cảm biến OMRON S3D2-CCD
Giá gốc: 1.800.000₫
Giá khuyến mại 1.650.000₫
| Type | Two inputs/two outputs | Two inputs/one output | |||
|---|---|---|---|---|---|
| Single- function |
Single-function (with OFF-delay) |
Single-function (AND/OR operation) |
Flip-flop function |
||
| Model | S3D2-DK | S3D2-EK | S3D2-AK | S3D2-BK | |
| Rated supply voltages | 100 to 240 VAC ± 10% 50/60Hz | ||||
| Power consumption | 15 VA max. | ||||
| Power supply for Sensor | 12 VDC ± 10% (includes all variations), 200 mA max. (with short-circuit protection) | ||||
| Connected Sensor | NPN transistor output (with sinking current of 18 mA min.) or contact output | ||||
| Input signals | ON | 0 to 4 V (5 mA min.) | |||
| OFF | 8 to 12 V (2 mA max.) | ||||
| Short-circuit current |
11 mA TYP (18 mA max.) | ||||
| Maximum applied voltage |
30 V | ||||
| Input response time | 0.1 ms | IN1 2 ms IN2 2 ms |
|||
| Output minimum pulse width | 10 ms max. | ||||
| Control output | Relay output SPST-NO × 2 250 VAC, 2A (cos φ = 1 ) |
Relay output SPDT (shared common) 250 VAC, 3 A (cos φ = 1) |
|||
| Life expectancy (relay output) |
Mechanical | 50,000,000 operations min. (switching frequency: 18,000 operations/h) | |||
| Electrical | 100,000 operations min. (switching frequency: 1,800 operations/h) | ||||
| Output response time | 10 ms max. | ||||
| Timer functions * | --- | OFF-delay 0.1 to 1 s 1 to 10 s selectable |
--- | ||
| Other functions | Signal input reverse | Signal input reverse AND/OR operating mode selection by wiring |
Signal input reverse Flip-flop function |
||
| Maximum allowable time of momentary power failure |
20 ms max. | ||||
| Ambient temperature range | Operating: -10 to +55°C, Storage: -25 to +65°C (with no icing) | ||||
| Ambient humidity range | Operating/storage: 35% to 85% | ||||
| Noise immunity | Operating power supply: 1,500 V (p-p) min.; pulse width: 100 ns, 1 μs; rise time: 1 ns Input/output: 1,200 V (p-p) min.; pulse width: 100 ns, 1 μs; rise time: 1 ns |
||||
| Dielectric strength | 1,500 VAC min. (between power supply terminals and I/O terminals, and between non-current-carrying parts) |
||||
| Vibration (destruction) | 10 to 55 Hz, double-amplitude of 0.75 mm for 2 hours each of the X, Y, and Z directions |
||||
| Weight | Approx. 140 g | ||||
